arjs-highnoon

This is a quick example of webAR using ar.js with a marker. It loads a gltf file, and has interaction built in when the user clicks on the model. The model will stay in perspective to the user as long as they keep the camera pointed at the marker. The model can be interacted with by clicking or tapping on it.

There is a fork of this project at arjs-highnoon-geolocation which uses ar.js geolocation to display the 3d entity in AR.

Requirements

• Node.js

Getting Started

You can run the ar example by uploading it to a SSL encrypted server and opening index.html

Installation Steps

1. Clone repo
2. Run npm install
3. Open index.html in your browser
4. If you make changes to the javascript files, run npm run build to get a new js bundle

---

The Asset can be viewed at https://jonnypage.github.io/arjs-highnoon/ using this pattern:

A printable pdf version can be found here

The interaction and animations are built using A-Frame animations and the A-Frame particle system

Documentation

File Structure

index.html
src
 ┣ assets
 ┃ ┣ itshighnoon.ogg
 ┃ ┣ mccree-base-spinner.png
 ┃ ┣ mccree.gltf
 ┃ ┣ overwatch-logo.png
 ┃ ┗ scene.bin
 ┣ js
 ┃ ┣ app.js
 ┃ ┗ arjs-highnoon.js
 ┗ patterns
 ┃ ┣ pattern-01-printable.pdf
 ┃ ┣ pattern-01.png
 ┃ ┗ pattern-01.patt
 dist
 ┗ bundle.js

index.html

<a-scene> is where arjs starts. It creates a A-Frame scene in which the camera is displayed, and all the assets live.

<a-assets> A-Frame has an asset management system that allows housing of assets in one place to preload and cache assets for better performance. Each item has a unique id tag that we reference later in our entities

<a-marker> Markers are a sort of simplified qr-codes. In AR.js we define specific 3D scenes for specific markers, so when the camera recognizes a marker, the web-app shows the 3D model on top of it.

<a-plane> This is the entity that spins at the base of the model when the animation plays. It contains a number of animation attributes to setup the different animations that play. Note the Extra animations are needed to reset the entity states before the animation can play again.

<a-entity id="particle-system"> This entity houses the A-Frame particle system. It emits Overwatch logos during the animation

<a-entity id="mccree-model"> This is the model entity. It is loaded via the asset management system by referencing the id of the <a-asset-item> setup earlier. It also houses the a-frame component mccreehandler used to listen for clicks/taps

<a-entity camera> The camera determines what the user sees.

arjs-highnoon.js

This is the main script used for the interaction and animation.

const audioHighNoon is the audio file used for the animation

const isAnimationPlaying is a booolean used to make sure the animation cannot be fired off again while it's playing.

AFRAME.registerComponent is the main handler. It references our model in index.html and an eventListener is added so we can listen for a click event.

onMccreeHit() is the function that runs when the click event fires.

It checks the isAnimationPlaying boolean to see if the animation is currently playing, and if it's not marks it as true to indicate the animation has started.

It then plays the audio audioHighNoon

Then triggers the animation for the spinning base via emit()

Followed by starting the particle system with the function startParticles()

Next there is a setTimeout function that waits for 2.5 seconds (2500ms) and stops the particle emitter with the function stopParticles()

Followed by another setTimeout function that waits for 4 seconds (4000ms) and toggles the isPlayingAnimation back to false so the animation can be started again.
