This workshop is meant to help you get started with Flutter and contributing to the ACS UPB Mobile app. We will be using the app as reference throughout the workshop, so please make sure you follow the steps described here to build and run it. The estimated time for completing the workshop is roughly 4h, but it can take longer if you follow the additional resource links. If you feel the time estimates are inaccurate or want to fill in the missing estimates, feel free to open a PR on this repo directly to fix them.
- Start contributing
- Get started with Flutter
- Get started with Firebase
If you're not familiar with git, consider learning the basics from one of the many resources available online. We recommend GitHub's resources, particularly the Git-It hands-on tutorial.
In order to start contributing, simply follow these 10 steps:
- Please make sure you've read the CONTRIBUTING.md file.
- Fork the ACS UPB Mobile repository.
- Clone the fork onto your system and open it as an Android Studio project.
- Don't forget to run
flutter pub getto update the dependencies. - Create a new branch by clicking on Git: master on the bottom right border in Android Studio and selecting New Branch. Its name should succinctly describe the modification/feature you are trying to add, so in this case something like
update_contributorswould be appropriate. - Add yourself to the list of contributors in the
README.mdfile. The recommended format is:[FirstName LastName](link_to_github_profile). - Commit and push the changes to the forked repository (Ctrl+K for committing, Ctrl+Shift+K for pushing in Android Studio).
- Create a pull request either from GitHub (you will see a message prompting you to create a PR when you open the forked repository) or Android Studio (VCS > Git > Create Pull Request). Make sure the PR points from the branch you created to the master branch in the acs-upb-mobile repo.
- Wait for the PR to be approved.
- Pat yourself on the back.
Once in a while you should sync your fork's master with the upstream (the original repo) master. To do this:
- In the repo on your machine add a new remote that points to acs-upb-mobile/master using the command:
git remote add upstream https://github.com/acs-upb-mobile/acs-upb-mobile.git. - Fetch the data from the upstream repo:
git fetch upstream. - Checkout your fork's
masterbranch:git checkout master. - Merge
upstreaminto your fork'smaster:git merge upstream/master. This may produce conflicts, unfortunately. To fix them, open the VCS menu in Android Studio, select Git and Resolve conflicts. - Push
masterto save the sync to GitHub either by using the Android Studio GUI or by callinggit push origin/master.
First of all, let's talk a bit about Flutter. It is a cross-platform framework developed by Google, meaning it allows us to use the same codebase for an application that can run on multiple operating systems (iOS, Android, Fuchsia, MacOS etc.) and the web. Flutter uses Dart as its main programming language. The Dart syntax is clean and looks similar to Java, while sharing certain useful features with languages like JavaScript and C# (for example, the async/await combo, with Futures in Dart being similar to Promises and Tasks in JavaScript and C# respectively).
In order to familiarize yourself with Dart, please go through this simple, 20-minute codelab before proceeding with this workshop.
Open Android Studio and create a new Flutter application. The sample app is very well explained through comments and it will help you understand the absolute basics of using Flutter. Analyze the folder structure and carefully read the following files:
lib/main.dart, which is the application itselfpubspec.yaml, which contains metadata necessary for building the application (similar tobuild.gradlein Android orInfo.plistin iOS)test/widget_test.dart, a simple test for the sample application
Run the test to make sure it works by right-clicking widget_test.dart and selecting Run. Run the application and play around with the code in main.dart, while taking advantage of the Hot Reload feature, which allows you to load changes in the code quickly into an already running app, without you needing to restart/reinstall it. For example, change the text and colours, reposition the widgets, make the counter count backwards (make sure you fix the test accordingly for that last one) etc.
Optimizing your workspace
On the left-hand Project panel in Android Studio, make sure you have the Project view open in the drop-down (not Android).
You can make the emulator window display on top of the IDE by going to Extended controls (...) in the emulator and enabling 'Emulator always on top' in Settings. This is especially useful when playing around with the UI in Flutter, as you will see the application update every time you save, thanks to the Hot Reload feature.
Troubleshooting tips
If Android Studio doesn't work properly (it doesn't highlight the code and errors or make suggestions), it may be a good idea to restart it. Click File > Invalidate Caches / Restart and hope for the best.
If the app doesn't work as expected, try restarting it (Hot Reload doesn't work with major code/flow changes). If that still doesn't work and you think your code is correct, you can try re-building it from scratch (run flutter clean to delete build files and then try flutter run or pressing the play button/Shift+F10 again).
Finally, if you see weird errors like classes not getting recognized, make sure Flutter is up to date (run flutter upgrade) and you're on the right branch (e.g. flutter channel beta if you're using the web version). Additionally, keep your dependencies up to date by running flutter pub get.
Subsequent sections will link to a tag in this repository which has the code you should end up with at the end of that section. You can use them to skip a section or cross-check your code if you have a problem. Keep in mind that the code snippets in this document are often not complete, since they are only meant to help you understand what you need to do. Avoid copy-pasting and try solving problems yourself before opening Spoiler sections or looking up the complete code in this repository.
The code that corresponds to this section can be found here.
Now that we have the basics covered, it's time to code. We'll start by butchering the sample app - first, let's change the colours. Remove the primarySwatch attribute from ThemeData and set primaryColor and accentColor to the ones in ACS UPB Mobile (hint: you can find them here). Note what changes in the app with each attribute.
Next, remove MyHomePage and MyHomePageState entirely. Create a new widget class called MainPage to replace it. In Flutter, widgets can be stateless or stateful. If it can change - for example, when a user interacts with it - it's stateful. Let's make ours a StatelessWidget for now, which returns a simple Scaffold. Congratulations, you now have an empty Flutter app!
IntelliSense tip #1: missing overrides
Take advantage of useful Android Studio features. For example, you can press Alt+Enter and Create missing overrides to easily define the build method of a new widget.
A Flutter app is essentially a widget tree. Most widgets don't need to be leaves in the tree, therefore they have a child or children attribute which allows us to nest other widgets within them. This is somehow similar to nested tags in HTML, in that parent widgets can control the appearance and properties of child widgets.
The most important method in a Widget is the build method, which describes the part of the UI represented by that widget. This method takes a BuildContext parameter, which has information about the location in the tree where the widget builds.
We will now attempt to create a layout similar to the grading view in ACS UPB Mobile:
The coloured strip at the top is called an AppBar. Let's give our Scaffold an AppBar with a meaningful title.
class MainPage extends StatelessWidget {
@override
Widget build(BuildContext context) {
return Scaffold(
appBar: AppBar(
title: Text('A meaningful title'),
),
);
}
}Note the comma at the end, where the title attribute is defined - since Flutter widgets have a nested appearance, this optional comma after the last attribute in a widget helps with formatting (Ctrl+Alt+L in Android Studio to reformat the code).
Keep in mind that ACS UPB Mobile uses a custom scaffold for consistency throughout pages in the app, meaning you will never need to define the AppBar yourself. Whenever you need to create a new page, you will start with an AppScaffold instead of a standard Scaffold.
The styled, elevated container that holds the pie chart in the screenshot above is called a Card. Let's try to create an empty card which takes up a third of the available space.
First, for the Card to actually be visible in the app, it needs to hold something. We won't add the pie chart just yet, but we can use a placeholder for now. The standard way of defining an 'empty' widget is through a Container with no attributes set, like this:
Scaffold(
appBar: AppBar(
title: Text('A meaningful title'),
),
body: Card(
child: Container(),
),
)If you save and look closely at the app, you can see the elevated margins of the card which now takes up the whole available space of the scaffold. Now, how do we make it only take up a third of the space? The naïve way would be to directly give it a specific size - the Container widget takes a height attribute, which we can set like this:
Card(
child: Container(
height: MediaQuery.of(context).size.height / 3,
),
)Wait, what? What did we just do there? It's simple, let's take it step by step. You already know that the context defines the current location in the widget tree. The .of(context) call, by design, is meant to return an instance of the widget it's used on by going up the tree of the context that is passed. In our case, it returns an instance of MediaQuery, which holds information about the size of the current window.
It is important to observe that this call returns the height of the screen itself (taking orientation into account). In other words, the card now takes up a third of the entire screen, not the available space in the scaffold. If we want the latter behaviour, we need to substract the height of the AppBar as follows:
Widget build(BuildContext context) {
var appBar = AppBar(
title: Text('A meaningful title'),
);
return Scaffold(
appBar: appBar,
body: Card(
child: Container(
height: (MediaQuery.of(context).size.height -
appBar.preferredSize.height) / 3,
),
),
);
}If this seems complicated, that's because it is. There is a better way to obtain this behaviour, by using a Column flex widget.
The two basic layout widgets in Flutter are Rows and Columns, which take a list of widgets and position them accordingly. Orientation and alignment are defined by the main axis and the cross axis, as such:
If we see our desired layout as a column, we want a card that takes up 1/3 of the available space, followed by an empty container that takes up the remaining 2/3. We can achieve this by using the Expanded widget's flex property like this:
Scaffold(
appBar: AppBar(
title: Text('A meaningful title'),
),
body: Column(
children: [
Expanded(
flex: 1,
child: Card(child: Container()),
),
Expanded(
flex: 2,
child: Container(),
)
],
),
)The flex factor is 1 by default, so specifying it for the card is optional. Expanded widgets take up all of the available space, and the flex attribute dictates how the space is distributed between the siblings.
IntelliSense tip #2: wrapping widgets
We had to wrap the Card in an Expanded widget, which in turn was wrapped by a Column widget. This happens frequently with Flutter development, and the larger the widget tree becomes, the harder it is sometimes to find the right place to add the appropriate brackets. Android Studio makes it easy - just Alt+Enter on the name of the widget you'd like to wrap, and select Wrap with widget!
If we look at the app, the layout is now similar to the grading view's background, except for one detail - there should be some spacing between the card and the edges of the screen. Spacing around a widget is called Padding. Let's use IntelliSense to quickly wrap the entire Column in a Padding of 8 pixels!
It should've automatically set the padding property to EdgeInsets.all(8.0). This means that we want a padding of 8 pixels on each side of the wrapped widget. We can use EdgeInsets to define exactly what kind of padding we want, for example EdgeInsets.only(left: 8.0, right: 4.0) to specify a value for each side and omit sides we don't need a padding on, EdgeInsets.symmetric(vertical: 2.0) if we want the same padding on corresponding sides, or EdgeInsets.fromLTRB(1.0, 2.0, 3.0, 4.0) to specify the padding for each side without needing named parameters (the order is left-top-right-bottom, LTRB).
The code that corresponds to this section can be found here. You should now have an app that looks like this:
We're ready to add the actual content!
Even though Flutter is a fairly new technology, the community is very active, and because it is open source there are countless available resources online that you can use. A good rule of thumb is, don't try to reinvent the wheel. Before starting to work on something, check if someone has done it before. You might find a useful package that you can add to the app, or maybe even a sample app that you can copy and modify for your needs.
One such example is, in our case, displaying some data in the form of a pie chart in Flutter. The pie_chart package is just a mere Google Search away. Get used to the resources offered by pub.dev - any package published will have documentation, statistics, instructions and an example usage. And the best part of open source? If the API doesn't quite suit your requirements but you'd like to use parts of a package, you can pretty much always just copy and modify the parts of their code you're interested in. To be safe, you can check the LICENSE file of the project, but generally all Dart packages have either an MIT or BSD license.
Life pro tip: If you do fiddle with someone's package, for instance to add functionality or expose some fields, it might be a good idea to even contribute to that package itself. E-mail the owner to tell them what you'd like to do, and if they say it's okay, submit a PR! Open source points on your résumé are always useful.
Back to our app - all we need to do to use this package is to add it to our pubspec.yaml file under dependencies:
dependencies:
pie_chart: <latest version>You can see the latest version in the package's name. Specifying it is not mandatory, but it is recommended. You will often see a caret next to the version specified in pubspec files (e.g. pie_chart: ^3.1.1), symbolising "version 3.1.1 or the newest compatible version", or ">=3.1.1 <4.0.0", since a new major version usually implies breaking changes.
Android Studio will prompt you to run flutter pub get to update the dependencies of your project. Do so.
Read the documentation of pie_chart and use the simple example to place a pie chart in our Card.
Spoiler - solution
Widget build(BuildContext context) {
Map<String, double> dataMap = new Map();
dataMap.putIfAbsent("Flutter", () => 5);
dataMap.putIfAbsent("React", () => 3);
dataMap.putIfAbsent("Xamarin", () => 2);
dataMap.putIfAbsent("Ionic", () => 2);
return Scaffold(
appBar: AppBar(
title: Text('A meaningful title'),
),
body: Padding(
padding: const EdgeInsets.all(8.0),
child: Column(
children: [
Expanded(
flex: 1,
child: Card(child: PieChart(dataMap: dataMap,)),
),
Expanded(
flex: 2,
child: Container(),
)
],
),
),
);
}Normally, we shouldn't do complex operations like populating a dataset in the build method, because it is called every time the page is reloaded or something changes. This is particularly important for stateful widgets, which are rebuilt often.
Hot Reload and look at the app. Now we have the pie chart and it looks alright! However, check what happens if you rotate the device. You will most likely see an overflow. Can you tell why it happens?
Spoiler - answer
The card's height is a third of the available height - which, in landscape mode, is the screen's width. This isn't enough to fit the entire content of the pie chart, and the package doesn't know how to deal with not having enough space.
Note that the ugly overflow warning is only visible in debug mode, for the developer to notice. In release mode, the user simply won't see the part of the widget that overflowed.
Build modes
Flutter offers three build modes:
- debug mode, used during development, allows the usage of IDE debugging tools and hot reload
- profile mode is used when you want to analyze performance
- release mode is the version seen by the end user
The performance in debug mode is almost always worse than the other two modes. Release mode cannot be used on an emulator, but if you want to take nice screenshots you can disable the debug banner from the Flutter Inspector tab found on the right edge of Android Studio.
Layout issues can usually be solved by either defining the layout differently (we've already seen that the same thing can be done in multiple ways in Flutter) or using a different layout for landscape and portrait with an OrientationBuilder.
Let's change the layout yet again to fix the overflow. The easiest way is to replace the Column with a ListView, which is essentially a scrollable column. We can simply replace the word 'Column' with 'ListView' and the app will work... but if we look at the console, we will see an exception:
Flutter errors are very verbose and, more often than not, will offer the exact solution to the problem and an explanation. In our case, it tells us that an Expanded widget can only be within a Flex widget (usually a Row or Column widget). We can just remove the Expanded widgets now and let the pie chart package control the size of the card on its own.
IntelliSense tip #3: removing widgets
Similar to wrapping widgets, we can also remove them easily from the tree using Android Studio. Press Alt + Enter while the cursor is on the name of any widget that has exactly one child, and you will get the option to remove it:
The code that corresponds to this section can be found here. The app should now look like this:
We want the user to be able to change the values of the items in the datamap, so we'll make an editable table containing two columns: Name (not editable) and Value (editable).
Let's add a header just under the card, with the Name label taking up 3/4 of the horizontal space, and the Value label the other 1/4 (hint: the wigets you need are Row, Expanded and Text). We should give it a padding as well - the standard 8 pixels on each side looks good.
The Text widget takes a style argument, which allows us to control the colour, size, font and weight of the text. You could manually set these properties, but for consistency in an app, it is generally recommended to use pre-defined styles from the app's theme. You can define these globally in the same place where you defined the primary and secondary colours earlier. For our header, we could use the headline6 text style, which you can obtain by calling Theme.of(context).textTheme.headline6, similar to how you used MediaQuery to get the screen size before. This is particularly important with apps with a customizable theme, like ACS UPB Mobile which has a dark mode and a light mode.
It should now look like this:
Spoiler - solution
ListView(
children: [
Card(child: PieChart(dataMap: dataMap)),
Padding(
padding: const EdgeInsets.all(8.0),
child: Row(
children: [
Expanded(
flex: 3,
child: Text(
"Name",
style: Theme.of(context).textTheme.headline6,
),
),
Expanded(
child: Text(
"Value",
style: Theme.of(context).textTheme.headline6,
),
),
],
),
),
],
)Keep in mind that, since ACS UPB Mobile is localized (works in both English and Romanian), you will never have to type string literals in the code itself, since everything needs to be defined in both languages in the localization files. The Flutter Intl Android Studio plugin generates localization code automatically, so make sure you have it installed. Say we need to define the strings for "Name" and "Value" - we would need to define them in intl_en.arb and intl_ro.arb (the plugin fires automatically when we save an .arb file), and then use them in the code as S.of(context).name and S.of(context).value.
Now, we need to add a row for each entry in the datamap. To keep things clean, create a method (List<Widget> buildTextFields(Map<String, double> dataMap, BuildContext context)) in the MainPage class, that generates a row with two TextFormField widgets for each (key, value) pair in the map. We only want to modify the values, so make the field that corresponds to the key (the name) readOnly. The value field should only accept numerical values (hint: check the keyboardType attribute).
For a nicer look, you can add some padding to these rows and some spacing between the columns (don't forget the header). Padding between list items can be added using a SizedBox instead of a Padding widget, if you want to avoid unnecessary nesting.
Spoiler - possible solution
List<Widget> buildTextFields(
Map<String, double> dataMap, BuildContext context) {
return dataMap
.map(
(key, value) => MapEntry(
key,
Padding(
padding: const EdgeInsets.symmetric(horizontal: 8.0),
child: Row(
children: [
Expanded(
flex: 3,
child: TextFormField(
initialValue: key,
readOnly: true,
),
),
SizedBox(width: 16.0),
Expanded(
child: TextFormField(
initialValue: value.toString(),
keyboardType:
TextInputType.numberWithOptions(decimal: true),
),
),
],
),
)),
)
.values
.toList();
}Concatenate the result to the end of the ListView's children, before the comma (ListView(children: [...] + buildTextFields(dataMap, context),)) and you should now have a table that looks like this:
You can now modify the values in the second column, but the datamap doesn't get updated. To update it, we should define the TextFormField's onChanged callback. Add a print statement to make sure it gets called correctly.
TextFormField(
initialValue: value.toString(),
keyboardType:
TextInputType.numberWithOptions(decimal: true),
onChanged: (newString) {
double newValue = double.tryParse(newString) ?? 0.0;
dataMap[key] = newValue;
print(key + ': ' + newValue.toString());
},
)Now, if we look at the console we can see it does get called when a value is changed, but the pie chart remains unchanged. Can you guess why that is?
Spoiler - answer
Our widget is stateless. It is built once and never gets updated, meaning that if the datamap changes afterwards, the widget won't be rebuilt. We need a stateful widget for this.
IntelliSense tip #4: stateless to stateful
Android Studio to the rescue again! It's easy to convert a stateless widget into a stateful one - just Alt+Enter on the name of the widget!
Alongside the build method, which is called every time the widget is updated, stateful widgets have an initState method that is called on the first build. Let's make the dataMap a class attribute and initialize it in initState instead of build:
class _MainPageState extends State<MainPage> {
Map<String, double> dataMap;
@override
void initState() {
super.initState();
dataMap = new Map();
dataMap.putIfAbsent("Flutter", () => 5);
dataMap.putIfAbsent("React", () => 3);
dataMap.putIfAbsent("Xamarin", () => 2);
dataMap.putIfAbsent("Ionic", () => 2);
}
@override
Widget build(BuildContext context) {
...
}When we change the state (in our case, by updating the data map), we need to notify the framework to process the change. We do this by making the change in a function that is passed to setState. The last thing we need to do for our pie chart to be interactive is to make a slight modification to the onChanged callback of our text fields:
onChanged: (newString) {
double newValue = double.tryParse(newString) ?? 0.0;
setState(() {
dataMap[key] = newValue;
});
print(key + ': ' + newValue.toString());
}We can now change the value of the items in the data map and watch the pie chart update as we do that. Please keep in mind that the Hot Reload functionality does not work with major changes such as making a widget stateful. In order to run the app, rebuilding is necessary. The code that corresponds to this section can be found here. The app should now look like this and be interactive:
Now, what do we do if we want to have another page? And more importantly, what do we do if we want to share data between those pages?
Say we want our home page to contain just the chart, centered and with the legend placed at the top. On the right side of the scaffold, we'd have an edit button that takes us to the page we've already build.
Let's rename our stateful widget to EditPage and create a new MainPage widget with the characteristics above. Leave out the edit button for now. You can put each of them in their own file to avoid having a very large main.dart file. You can also change the title on the app bar for each of them accordingly ('View chart'/'Edit chart').
Spoiler - solution
class MainPage extends StatelessWidget {
@override
Widget build(BuildContext context) {
Map<String, double> dataMap = new Map();
dataMap.putIfAbsent("Flutter", () => 5);
dataMap.putIfAbsent("React", () => 3);
dataMap.putIfAbsent("Xamarin", () => 2);
dataMap.putIfAbsent("Ionic", () => 2);
return Scaffold(
appBar: AppBar(
title: Text('View chart'),
),
body: PieChart(
dataMap: dataMap,
legendPosition: LegendPosition.top,
),
);
}
}Now, we need to add the edit button to the scaffold's app bar. This is done by adding an IconButton as an action to the AppBar. The onPressed callback on this button uses Navigator to open an EditPage.
AppBar(
title: Text('View chart'),
actions: [
IconButton(
icon: Icon(Icons.edit),
onPressed: () => Navigator.of(context)
.push(MaterialPageRoute(builder: (context) => EditPage())),
)
],
)The pages in an app act like a stack - if we push a new page, the user can navigate back to the previous page in the stack by pressing the back button (equivalent to popping the stack). We have full control of the stack with various Navigator methods - for instance, if we want to replace the current page, we can use pushReplacement.
Alternatively, a cleaner way to deal with navigation is through named routes. Replace home: MainPage() in the MaterialApp with:
routes: {
'/': (context) => MainPage(),
'/edit': (context) => EditPage(),
}The default route when the app opens is '/', but you can specify a different one using initialRoute, should you need to. You can now open the edit page by simply calling:
Navigator.of(context).pushNamed('/edit')An interesting effect of using named routes is that they are accessible through the URL in the web version. Try running the app on the web, by selecting "Chrome (web)" from the device dropdown. You will notice that, if the URL is, for instance, 'http://localhost:52755/#/', you can access 'http://localhost:52755/#/edit' to get to the edit page.
Right now, each page uses a separate data map. If we used MaterialPageRoute and built the EditPage instance in the MainPage to navigate, we could technically pass the data map as a parameter to EditPage's constructor. However, changes made on the edit page would still not be visible on the main page, since we couldn't notify the main page of the changes. There are multiple ways to handle this, but ACS UPB Mobile uses the provider package.
Provider is a dependency injection framework which can be used to manage state in a Flutter application. Providers offer an easy way to encapsulate state and share it with a branch of the widget tree. It achieves that by being defined as the parent of that branch.
Install the provider package (don't forget to run flutter pub get) and create a new source file called data_provider.dart in the lib/ folder. Define the DataProvider class here, like this:
class DataProvider with ChangeNotifier {
Map<String, double> _dataMap;
DataProvider() {
_dataMap = new Map();
_dataMap.putIfAbsent("Flutter", () => 5);
_dataMap.putIfAbsent("React", () => 3);
_dataMap.putIfAbsent("Xamarin", () => 2);
_dataMap.putIfAbsent("Ionic", () => 2);
}
Map<String, double> get dataMap => _dataMap;
set dataMap(Map<String, double> newDataMap) {
_dataMap = newDataMap;
notifyListeners();
}
}It initialized the data map that we know in the constructor, and has a custom getter and setter - with the setter calling notifyListeners() to notify any widget that is using this Provider about the change.
IntelliSense tip #5: auto import
When using a class for a first time in a file, you need to specify the library you want to import it from (be it part of the framework, a package, or your own codebase). You never need to actually remember the library because Android Studio gives you options to import when you start typing the class name, like with the ChangeNotifier we just used:
Just select the right option (look at the package name on the right side) and press Tab or Enter to confirm, and Android Studio will automatically add a line like import 'package:flutter/foundation.dart'; to the beginning of the file. If you want to order the imports (alphabetically), you can press Ctrl+Alt+O.
Note that some framework components, like ChangeNotifier, can be found in multiple libraries. The one you choose to import won't affect the functionality, but we usually prefer to go with the narrow-scope libraries if possible. In this case, the rule of thumb would be:
foundation.dart (Core Flutter framework) > widgets.dart (Flutter widgets framework) > material.dart (Android-like/Material Design components, used most often in ACS UPB Mobile) > cupertino.dart (iOS design components)
Now add the provider you created to the root of the application:
void main() {
runApp(ChangeNotifierProvider(
create: (context) => DataProvider(), child: MyApp()));
}There are different types of Providers, but ChangeNotifierProvider is the right one for our needs. Now, to fetch this data map from the provider in both of our pages, we simply need to call:
Provider.of<DataProvider>(context).dataMap;The <DataProvider> type specification is optional because we only have one Provider as the parent, but becomes necessary when there are multiple Providers in the tree. Finally, we should add a 'Save' button to the edit page which registers the changes with our DataProvider:
class _EditPageState extends State<EditPage> {
Map<String, double> dataMap;
@override
void initState() {
super.initState();
dataMap = Provider.of<DataProvider>(context, listen: false).dataMap;
}
@override
Widget build(BuildContext context) {
return Scaffold(
appBar: AppBar(
title: Text('Edit chart'),
actions: [
FlatButton(
child: Text('Save'),
onPressed: () {
Provider.of<DataProvider>(context, listen: false).dataMap =
dataMap;
Navigator.of(context).pop();
},
),
],
),
body: ...
}
...
}The listen: false attribute tells the provider that the particular context in which it is used does not need to listen for changes. In our case, the Edit page does not need to listen for changes, but the main page does (listen is true by default, so we don't need to specify it when using the Provider there). The code that corresponds to this section can be found here. If you did everything correctly, the pie chart on the main page should now be updated when you press 'Save' on the edit page. After rebuilding the app and running it, you should see something like this:
BLoC
ACS UPB Mobile uses a variation of the BLoC (Business Logic Component) design pattern used in Flutter development. This variant utilizes Providers to avoid boilerplate code.
With BLoC, every page in the app will have three components:
- the UI/Flutter layer, also called the view, which acts as a middleman between the user and the BLoC layer (in this workshop, the
MainPageandEditPage) - the BLoC layer, which we also refer to as the Provider or service, contains the actual business logic and communicates with the database (in this workshop, the
DataProvider) - the data layer or the data model contains simple data classes which represent the data that is to be displayed in the UI, and is provided by the BLoC (in this workshop, we don't need a custom class because we simply use a
Map<String, double>as our model)
Now we have the functionality we wanted, but we've only tested it manually. Let's add some automated testing in the test/widget_test.dart file.
The simplest thing to test is the existence of the legend labels for the pie chart:
testWidgets('Test names', (WidgetTester tester) async {
await tester.pumpWidget(ChangeNotifierProvider(
create: (context) => DataProvider(), child: MyApp()));
expect(find.text('Flutter'), findsOneWidget);
expect(find.text('React'), findsOneWidget);
expect(find.text('Xamarin'), findsOneWidget);
expect(find.text('Ionic'), findsOneWidget);
});Note that, when pumping the app, you need to pump it with the appropriate Provider. Another thing we can test easily is navigation:
testWidgets('Test navigation', (WidgetTester tester) async {
await tester.pumpWidget(ChangeNotifierProvider(
create: (context) => DataProvider(), child: MyApp()));
expect(find.byType(MainPage), findsOneWidget);
expect(find.byType(EditPage), findsNothing);
await tester.tap(find.byIcon(Icons.edit));
await tester.pumpAndSettle();
expect(find.byType(MainPage), findsNothing);
expect(find.byType(EditPage), findsOneWidget);
await tester.tap(find.text('Save'));
await tester.pumpAndSettle();
expect(find.byType(MainPage), findsOneWidget);
expect(find.byType(EditPage), findsNothing);
});Remember that, after actions like tapping certain buttons, you need to wait for the animations to finish by calling await tester.pumpAndSettle().
Now, right-click widget_test.dart and select Run > tests in widget_test... to make sure the tests work. If you don't see that option, you may need to Edit configurations and add a Flutter Test configuration for the test/ folder.
To test that the most important feature - editing the chart data - actually works, we first need to initialise the DataProvider and test the initial values:
DataProvider provider = DataProvider();
Map<String, double> dataMap = provider.dataMap;
expect(dataMap['Flutter'], equals(5));
expect(dataMap['React'], equals(3));
expect(dataMap['Xamarin'], equals(2));
expect(dataMap['Ionic'], equals(2));Then , we pump the app, open the edit page, change the value in one of the fields and press 'Save':
await tester.pumpWidget(
ChangeNotifierProvider(create: (context) => provider, child: MyApp()));
await tester.tap(find.byIcon(Icons.edit));
await tester.pumpAndSettle();
Finder flutterValueField = find.widgetWithText(TextFormField, '5.0');
await tester.enterText(flutterValueField, '10');
await tester.tap(find.text('Save'));
await tester.pumpAndSettle();Finally, we test the new values:
expect(dataMap['Flutter'], equals(10));
expect(dataMap['React'], equals(3));
expect(dataMap['Xamarin'], equals(2));
expect(dataMap['Ionic'], equals(2));Run this last test as well to make sure everything works as expected. The code that corresponds to this section can be found here.
GitHub Actions
ACS UPB Mobile uses GitHub Actions for continuous integration & continuous deployment. What this means is, with every push to the repository, the tests are run in a virtual machine and the last commit pushed will be marked with a checkmark if the tests pass and an x if at least one test fails. If a new tag is added and the tests pass, the new version is automatically deployed onto the website and as an apk on GitHub.
Ideally, every new feature should have its own tests or at least be added to the integration test, which runs on both orientations and multiple screen sizes and navigates to all pages in the app to make sure there are no obvious errors like overflows.
Our app is now interactive and we can modify the chart data as we please. However, these modifications are not persistent - they are lost if we restart the app. The go-to way to persist data is by using a database (e.g. SQLite, Hive or Firebase, see section Get started with Firebase), but for very simple data such as ours, we can store key-value data on the disk using the shared_preferences plugin. It works by wrapping platform-specific persistent storage for simple data (NSUserDefaults on iOS and macOS, SharedPreferences on Android, etc.).
ACS UPB Mobile uses the preferences plugin (which in turn depends on shared_preferences) to store simple data such as settings. Let's use this in our app as well, add the dependency to the pubspec.yaml file.
As per the package documentation, you need to call PrefService.init() before running the app. Change the main method to:
import 'package:preferences/preferences.dart';
void main() async {
await PrefService.init();
runApp(ChangeNotifierProvider(
create: (context) => DataProvider(), child: MyApp()));
}Because the PrefService.init() call is asynchronous, we need to use the await keyword to make sure it completes before the runApp call. The await keyword can only be used in asynchronous functions, hence why we need to mark main as async. If we don't use await, the runApp call would be made while the PrefService.init() method is still running.
Asynchronous programming in Dart
Dart makes asynchronous programming easier with async/await and Futures. Asynchronous operations let your program complete work while waiting for another operation to finish. This is particularly important when handling UI - the interface operations need to be handled on the main thread for the app to run smoothly, while more complex operations such as network calls and reading from files should be handled in a background thread.
Key terms:
- synchronous operation: A synchronous operation blocks other operations from executing until it completes.
- asynchronous operation: Once initiated, an asynchronous operation allows other operations to execute before it completes.
async: You can use theasynckeyword before a function’s body to mark it as asynchronous.await: You can use theawaitkeyword to get the completed result of an asynchronous expression. The await keyword only works within an async function. -future: A future is an instance of theFutureclass. A future represents the result of an asynchronous operation, and can have two states: uncompleted or completed.
To understand asynchronous programming in Dart, consider completing this 50-minute codelab.
The shared_preferences plugin only allows for the following data types to be stored under a key: bool, double, int, String, List<String>. Because we'd like to store a Map<String, double>, we could store it as two string lists. Note that you should never do this with more complex data, as it adds the overhead of converting between collections, when the whole point of Maps in general is to be very fast.
To set the default values we've been using so far, add the following in your main function, after the initialization:
PrefService.setDefaultValues({
'data_map_keys': ['Flutter', 'React', 'Xamarin', 'Ionic'],
'data_map_values': ['5', '3', '2', '2'],
});If you try to run the app now, you will get an error. As is often the case with Flutter, the error tells you exactly what to do to fix it: you need to add WidgetsFlutterBinding.ensureInitialized(); as the first line in your main function.
Now we need to change our Provider to use the new way to save data. This being very easy to do is one of the most important benefits of providers. First, instead of initialising the map, the constructor should now read it from the preferences:
DataProvider() {
var keys = PrefService.get('data_map_keys');
var values = PrefService.get('data_map_values');
_dataMap = Map<String, double>.from(keys.asMap().map(
(index, key) => MapEntry(key, double.tryParse(values[index] ?? 0))));
}Second, we need to update the custom setter:
set dataMap(Map<String, double> newDataMap) {
_dataMap = newDataMap;
PrefService.setStringList(
'data_map_keys', List<String>.from(_dataMap.keys));
PrefService.setStringList('data_map_values',
List<String>.from(_dataMap.values.map((value) => value.toString())));
notifyListeners();
}We need the Iterable<T>.from calls to convert between different types of iterables (Maps, Lists). If you try to run the app without these calls, you will get type errors.
Run the app - it should work the same way as before, except if you close it and open it again, the changes will still be there.
Every time you change something or do something new, you need to remember to run the tests before committing to the repository. If we try to run our tests now, they will fail because PrefService was not initialised.
In Flutter testing, we can use setUp to define some code that needs to run before each test (or setUpAll for code that needs to run once before all tests). Add the following code to widget_test.dart to make the tests pass again:
setUp(() {
WidgetsFlutterBinding.ensureInitialized();
PrefService.enableCaching();
PrefService.cache = {};
PrefService.setStringList(
'data_map_keys', ['Flutter', 'React', 'Xamarin', 'Ionic']);
PrefService.setStringList('data_map_values', ['5', '3', '2', '2']);
});Congratulations, you now have a fully functional, interactive pie chart app with persistent data! You can find the code here.
You can keep playing around with the app to learn more about Flutter development. Here are some suggestions on what you could do:
- When you press enter on one field on the edit page, change focus to the following field (hint:
FocusNode). - Add a "Total" field on the edit page (check out the grading view screenshot in the Create the layout section; the only new widget you would need to copy that layout is
Divider). - Make it so you can change keys in the data map as well, not just the values.
- Add a way for users to add new entries in the data map. There are at least two ways to do that:
- Add a plus button (maybe a
FloatingActionButton) that makes a new row of text fields appear. - Make a new, empty row of text fields appear if both fields in the last row have data in them.
- Add a plus button (maybe a
- Add form validation to make sure the data in the text fields has the format you want (e.g. non-zero numbers for the values, maybe check that the names are capitalized etc.)
Be creative, and remember to update the tests accordingly!
ACS UPB Mobile uses Firebase services for analytics (Google Analytics), authentication (Firebase Auth) and storage (Firestore, Cloud Storage). In order to get familiar with it, this section will guide you through the process of adding and using Firebase in your app. If you skipped the previous section, you can start with the code here.
Go to the Firebase console and Create a project. Give it a name (like "Flutter workshop") and enable Google Analytics (you may need to create a Google Analytics account - you can call it "Personal projects" and reuse it whenever you'd like to play around with Firebase). When creation is complete, you will need to add it to your Flutter app on each individual platform (Android, iOS and Web).
The easiest way to access Firebase services in Flutter is by making use of flutterfire plugins, which provide an easy-to-use API for Flutter applications. ACS UPB Mobile currently uses firebase_analytics, firebase_auth, cloud_firestore and firebase_storage, all of which depend on firebase_core. These packages offer many useful features for all three target platforms (Android, iOS, Web), except cloud_firestore, which (as of July 2020) still lacks Web support.
Add the most recent versions of firebase_core, firebase_analytics and cloud_firestore to the project's pubspec.yaml file. Remember to run flutter pub get.
- Click the Android icon in the Firebase console to launch the setup workflow. You can find the Android package name in your Flutter project's
android/app/build.gradlefile if you search for theapplicationIdfield. - Download
google-services.jsonand save it in theandroid/app/folder. - Follow the instructions to enable Firebase for the Android app.
- Update
minSdkVersionin the app-levelbuild.gradlefile to21. - You may need to run
flutter cleanand re-build the application for the verification step. - In the Android Studio console, run
flutter packages get.
Note: If you get an error saying "Plugin project :firebase_auth_web not found. Please update settings.gradle.", try the fix here.
Skip this step if you do not have a MacOS computer.
- Click "Add app" in the Firebase console and select "iOS" to launch the setup workflow. The bundle ID should be the same as the
applicationIdyou used earlier for the Android setup, or you can find it inios/Runner.xcodeproj/project.pbxprojif you search forPRODUCT_BUNDLE_IDENTIFIER. - Download
GoogleService-Info.plistand save it in theios/Runnerfolder. - Follow the instructions to enable Firebase for the Android app. You may need to run
flutter cleanand re-build the application for the verification step. - In the Android Studio console, run
flutter packages get.
- Click "Add app" in the Firebase console and select "Web" to launch the setup workflow.
- Enable hosting. You can keep the default domain name.
- Follow the instructions and add the scripts to
web/index.htmlin your project before the "main.dart.js" script. - Run
flutter build webbefore following the hosting instructions. Make sure you selectbuild/webas the public directory when runningfirebase init:
Your code should now look like this, but keep in mind you should use your own configuration. The Firebase console offers all sorts of useful information about your app(s), including usage statistics.
Time to create our Firestore instance. Go to the Firebase console and open the Database view from the Develop category. Click Create database, select Start in production mode and choose a location for the cloud resource (the closer to the userbase, the better).
Firestore and its data model
Cloud Firestore is a noSQL database that organises its data in collections and documents.
Collections are simply a list of documents, where each document has an ID within the collection.
Documents are similar to a JSON file (or a C struct, if you prefer), in that they contain
different fields which have three important components: a name - what we use to refer to the
field, similar to a dictionary key -, a type (which can be one of string, number,
boolean, map, array, null - yeah null is its own type -, timestamp, geopoint,
reference - sort of like a pointer to another document), and the actual value, the data
contained in the field.
In addition to fields, documents can contain collections... which contain other documents... which
can contain collections, and so on and so forth, allowing us to create a hierarchical structure
within the database.
More information about the Firestore data model can be found here.
After the database is initialized, create a collection (you can call it 'data' or whatever you want) with a single document (you can allow Firebase to give it an automatic unique ID) containing the data map we've been using so far, containing number fields.
Time to update the Provider once again, this time to use our cloud-based database. We no longer need the preferences plugin and its setup, but we can keep it in the app in case we want to use it for something else.
We no longer need to initialize something in the constructor, so we can delete it. We will create two async methods for fetching and updating the data in the database.
In order to fetch the information, we use the name of the collection and the documentID and await for the network response. We then extract the data_map field from the response and convert it to a Map<String, double>.
Future<Map<String, double>> fetchDataMap() async {
DocumentSnapshot snap =
await _db.collection('data').document('vztH0rlKnqYCOyzK11HS').get();
_dataMap = Map<String, double>.from(snap.data['data_map']
.map((key, value) => MapEntry(key, value.toDouble())));
notifyListeners();
return _dataMap;
}Conversion is relatively easy to do because Firebase stores data as maps and our data model is a simple Map. For custom data classes, you would need to implement a way to convert between an instance of the class and a DocumentSnapshot or a map. ACS UPB Mobile does that by creating extensions on the data classes with methods like fromSnap and toData (a good example is here). Extensions extend the functionality of a class by adding new attributes, constructors or methods. They are usually made on classes you cannot modify (such as pre-defined classes like StatelessWidget or even String), but in our case help with the separation of concerns. The data layer should not have any database-specific functionality (as per the design pattern we described in the Passing data section), hence why we define this behavior in the service layer (our provider).
The process of updating data is fairly similar:
void updateDataMap(Map<String, double> newDataMap) async {
DocumentReference ref =
_db.collection('data').document('vztH0rlKnqYCOyzK11HS');
await ref.updateData({'data_map': newDataMap});
}Our setter will now call updateDataMap instead of updating the preferences. We won't bother waiting for it, but depending on the situation, in other apps you may want to wait and report an error if it occurs. You could, for instance, wrap the call in a try/catch block.
set dataMap(Map<String, double> newDataMap) {
_dataMap = newDataMap;
updateDataMap(newDataMap);
notifyListeners();
}The dataMap field now acts as a simple in-memory cache. It will be null if fetchDataMap was not called successfully, therefore we must change MainPage to make sure it does call it.
Flutter has a very useful widget for dealing with futures, called a FutureBuilder. It can display something different depending on whether the future is complete or not. We will use it as the body of our scaffold, and make it display a progress indicator while waiting for the data, a pie chart if the data is fetched successfully or an error message otherwise.
body: FutureBuilder<Map<String, double>>(
future: Provider.of<DataProvider>(context).fetchDataMap(),
builder: (context, snapshot) {
if (snapshot.connectionState == ConnectionState.done) {
if (snapshot.hasError) {
print(snapshot.error);
return Center(child: Text('Something went wrong.'));
}
return PieChart(
dataMap: snapshot.data ?? {},
legendPosition: LegendPosition.top,
);
} else {
return Center(child: CircularProgressIndicator());
}
})If you run the app, it should now display the "Something went wrong" error message. If you look at the console, you will see an error like W/Firestore(32521): (21.3.0) [Firestore]: Listen for Query(data/vztH0rlKnqYCOyzK11HS) failed: Status{code=PERMISSION_DENIED, description=Missing or insufficient permissions., cause=null}. We will fix it in a bit, for now let's try to open the edit page. You'll see the ugly Flutter exception screen because we don't deal with a lack of data in this page. The simplest way to do that is by updating the body of the scaffold to check whether the cached dataMap is null:
body: (dataMap == null)
? Center(child: Text('No data to edit'))
: Padding(
...Now that the edit page handles lack of data, we can do even more - restrict access to it altogether if there is nothing to edit. If the onPressed callback of an IconButton is null, the button will appear disabled and will not respond to touch:
IconButton(
icon: Icon(Icons.edit),
onPressed: dataMap == null
? null
: () => Navigator.of(context).pushNamed('/edit'),
)Do keep in mind that users on the web version can still access the edit page by changing the URL, so it's important that we handle the null value inside the page as well as restricting access.
Now, to fix the PERMISSION_DENIED error. We need to allow read/write access to our data collection from the Firebase console. Go back to the database and open the Rules menu. Here we can define custom security rules which control who can do what in our database. You can find more information about Firebase Security Rules here, but for now we will simply allow access to our collection by changing the rules like this:
rules_version = '2';
service cloud.firestore {
match /databases/{database}/documents {
match /data/{data}/{document=**} {
allow read, write: if true
}
}
}
Publish the rules and reload the app. The pie chart should now show, but the edit button will probably still be greyed out - for it to be updated accordingly, you would need to wrap the entire Scaffold into a FutureBuilder and use the data from the snapshot to verify whether the button should be disabled. You can do that later, for now just restarting the app should do the trick.
If the data fetching is very fast and you'd like to make sure that the loading indicator works as expected, you might need to make the fetchDataMap take longer. You can temporarily add something like await Future.delayed(Duration(seconds: 5)) to make it last 5 seconds longer so you have time to see the progress indicator.
Try to edit the chart while having the document open in the Firebase console. You will see it update immediately! Now whoever uses the app can see and make live updates. If something isn't working correctly, you can check the code here (just remember to use your own configuration and unique documentID).
